Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
UVZ1V471MPD | ||
|---|---|---|
Digi-Key Part Number | 493-1321-ND | |
Manufacturer | ||
Manufacturer Product Number | UVZ1V471MPD | |
Description | CAP ALUM 470UF 20% 35V RADIAL | |
Detailed Description | 470 µF 35 V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | UVZ1V471MPD Models | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Package | Bulk | |
Product Status | Not For New Designs | |
Capacitance | ||
Tolerance | ±20% | |
Voltage - Rated | 35 V | |
ESR (Equivalent Series Resistance) | - | |
Lifetime @ Temp. | 2000 Hrs @ 105°C | |
Operating Temperature | -55°C ~ 105°C | |
Polarization | Polar | |
Ratings | - | |
Applications | General Purpose | |
Ripple Current @ Low Frequency | 460 mA @ 120 Hz | |
Lead Spacing | 0.197" (5.00mm) | |
Size / Dimension | 0.394" Dia (10.00mm) | |
Height - Seated (Max) | 0.689" (17.50mm) | |
Surface Mount Land Size | - | |
Mounting Type | ||
Package / Case | Radial, Can |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | |
| Video File | Doctor Capacitor Episode Three: Failure Modes Doctor Capacitor Episode Two: Terms Doctor Capacitor® Episode Eight: Nichicon Kitchen (or, all about soldering) Doctor Capacitor® Episode Nine: You Callin' Me? Doctor Capacitor® Episode Seven: What's In The Mail, Doc? |
| Design Resources | 20 W Non-Isolated Buck LED Driver Using PL LNK460KG |
| PCN Part Status Change | Mult Series NRND 23/Jun/2022 |
| HTML Datasheet | |
| EDA Models | UVZ1V471MPD Models |
| Product Drawings |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8532.22.0020 |
In-Stock: 4 078
Quantity
All prices are in NOK
Bulk
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | kr 7,38000 | kr 7,38 |
| 10 | kr 4,95300 | kr 49,53 |
| 50 | kr 3,94200 | kr 197,10 |
| 100 | kr 3,25450 | kr 325,45 |
| 500 | kr 2,54300 | kr 1 271,50 |
| 1 000 | kr 2,16143 | kr 2 161,43 |
| 2 500 | kr 2,03431 | kr 5 085,78 |
| 5 000 | kr 1,90717 | kr 9 535,85 |
Substitutes (24)
| Part No. | Manufacturer | Quantity Available | Digi-Key Part No. | Unit Price | Substitute Type |
|---|---|---|---|---|---|
| UKA1V471MPD | Nichicon | 6 034 | 493-15339-ND | kr 14,87000 | Upgrade |
| UPJ1V471MHD6 | Nichicon | 497 | 493-15671-ND | kr 12,86000 | Similar |
| UPJ1V471MPD | Nichicon | 954 | 493-11101-ND | kr 10,17000 | Similar |
| UPM1V471MHD6 | Nichicon | 581 | 493-15791-ND | kr 16,32000 | Similar |
| UPM1V471MPD | Nichicon | 1 132 | 493-11136-ND | kr 11,96000 | Similar |
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | 493-1321 |
| Standard Package | 1 800 |
