Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
UVZ1C101MDD1TD | ||
|---|---|---|
Digi-Key Part Number | 493-13439-1-ND - Cut Tape (CT) 493-13439-3-ND - Tape & Box (TB) | |
Manufacturer | ||
Manufacturer Product Number | UVZ1C101MDD1TD | |
Description | CAP ALUM 100UF 20% 16V RADIAL | |
Detailed Description | 100 µF 16 V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | UVZ1C101MDD1TD Models | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Package | Cut Tape (CT) Tape & Box (TB) | |
Product Status | Not For New Designs | |
Capacitance | ||
Tolerance | ±20% | |
Voltage - Rated | 16 V | |
ESR (Equivalent Series Resistance) | - | |
Lifetime @ Temp. | 1000 Hrs @ 105°C | |
Operating Temperature | -55°C ~ 105°C | |
Polarization | Polar | |
Ratings | - | |
Applications | General Purpose | |
Ripple Current @ Low Frequency | 115 mA @ 120 Hz | |
Ripple Current @ High Frequency | 172.5 mA @ 10 kHz | |
Lead Spacing | 0.079" (2.00mm) | |
Size / Dimension | 0.197" Dia (5.00mm) | |
Height - Seated (Max) | 0.492" (12.50mm) | |
Surface Mount Land Size | - | |
Mounting Type | ||
Package / Case | Radial, Can |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | |
| Video File | Doctor Capacitor Episode Three: Failure Modes Doctor Capacitor Episode Two: Terms Doctor Capacitor® Episode Eight: Nichicon Kitchen (or, all about soldering) Doctor Capacitor® Episode Nine: You Callin' Me? Doctor Capacitor® Episode Seven: What's In The Mail, Doc? |
| Design Resources | 20 W Non-Isolated Buck LED Driver Using PL LNK460KG |
| PCN Part Status Change | Mult Series NRND 23/Jun/2022 |
| HTML Datasheet | |
| EDA Models | UVZ1C101MDD1TD Models |
| Product Drawings |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8532.22.0020 |
In-Stock: 17 918
Quantity
All prices are in NOK
Cut Tape (CT)
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | kr 3,24000 | kr 3,24 |
| 10 | kr 2,10200 | kr 21,02 |
| 50 | kr 1,47360 | kr 73,68 |
| 100 | kr 1,18960 | kr 118,96 |
| 500 | kr 0,88344 | kr 441,72 |
| 1 000 | kr 0,77299 | kr 772,99 |
Tape & Box (TB)
| Qty | Unit Price | Ext Price |
|---|---|---|
| 2 000 | kr 0,73621 | kr 1 472,42 |
| 4 000 | kr 0,68100 | kr 2 724,00 |
| 10 000 | kr 0,64419 | kr 6 441,90 |
| 14 000 | kr 0,61107 | kr 8 554,98 |
| 50 000 | kr 0,55217 | kr 27 608,50 |
| 100 000 | kr 0,48775 | kr 48 775,00 |
Manufacturers Standard Package
Substitutes (3)
| Part No. | Manufacturer | Quantity Available | Digi-Key Part No. | Unit Price | Substitute Type |
|---|---|---|---|---|---|
| UKA1C101MDD1TD | Nichicon | 4 000 | 493-4638-3-ND | kr 1,38571 | Upgrade |
| UVY1E101MDD1TD | Nichicon | 1 258 | 493-12902-1-ND | kr 3,91000 | Upgrade |
| 16PX100MEFCTA5X11 | Rubycon | 1 536 | 1189-1533-1-ND | kr 2,91000 | Direct |
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | 493-13439-3 493-13439-1 |
| Standard Package | 2 000 |
